Digitally controlled high-voltage DC power supplies, 1.5 kV to 30 kV, 500 W to 3 kW, with reversible or floating output. One platform, regulated to a hundredth of a percent.
Every HVX-Series supply shares the same digital regulation core, the same color TFT control, and the same Ethernet, RS232, and SCPI interfaces. Pick the voltage and power class your test bench needs.
High-current 1.5 kV class for loads that draw real amperage. Floating, potential-free output or electrically reversible polarity, depending on the variant.
Mid-voltage workhorses for HV test and characterization. Positive, negative, or electrically reversible polarity, earth-referenced, with 16-bit setting resolution.
High-voltage, low-current class for precision HV references, capacitor charging, and breakdown work. Tight ripple and stability hold steady out to 30 kV.
DC output to 30 kV across the line, with voltage classes from 1.5 kV up.
Power classes of 500 W, 2 kW, and 3 kW from a single-phase AC input with active PFC.
Up to 2000 mA on the high-current 1.5 kV class for demanding loads.
Voltage and current stability within 0.01% of nominal over an 8 hour window.
Electrically reversible positive or negative, earth-referenced, or floating potential-free output.
Ethernet and RS232 on board with a full SCPI command set for automated test integration.
16-bit voltage and current setting from roughly 0.01% to 100% of nominal.
2U high (3.5 in), 19-inch rack-mount or benchtop with an integrated adapter.
Each application ships with a technical brief covering setup, method, and the HVX-Series configuration that fits. Click for more or submit your application.
High-voltage qualification, reliability, and quality testing across the semiconductor production floor.
E-MobilityUp to 2 A at 1.5 kV for inverter, converter and motor test, with a floating output for potential-free rigs.
Power ElectronicsDouble-pulse switching characterization for wide-bandgap SiC and GaN power devices.
ProductionRepeatable, SCPI-driven HV test stations for end-of-line quality gates and pass/fail screening.
MetrologyHolds calibration points with 0.01 percent eight-hour stability and 16-bit setting, read through a reference divider and voltmeter.
ResearchA flexible, fully programmable HV source for university and corporate research benches.
Pulsed PowerControlled, repeatable charging for pulsed-power and energy-storage experiments.
AnalyticalTime-of-flight acceleration and liner rails within a stated mass budget, plus electrode conditioning and high-voltage qualification.
ImagingLow-ripple bias to 30 kV for benchtop XRF, soft X-ray sources and tube conditioning.
BeamStable, low-ripple extraction, focus and sub-30 kV acceleration stages, with arc detection.
ProcessElectrospinning, sputter bias, electrostatic chucks and laboratory precipitation cells to 30 kV, with ramp control and arc detection.
DetectionKilowatt-class supplies for ion sources, accelerator electrodes, bias buses and high-voltage test; PMT and SiPM bias belongs on low-current sources.
Talk to a Berkeley Nucleonics engineer about the HVX-Series voltage class, power, and polarity that fit your test bench.
