PCO-6131 | 125A Output Current Pulsed / CW Laser Diode Driver Module
The EVO Series delivers exceptional precision, rapid control, and user-friendly operation in a compact, high-power-density package—ideal for demanding high-voltage applications.
- Power ratings: 2 kW or 3 kW
- Voltage classes: 0–1.5 kV DC, 0–5 kV DC, 0–10 kV DC (up to 20 kV in select configs)
- Currents: from 0.2 A to 2 A (model-dependent)
- Compact form factor: only 2U rack height (benchtop or 19″ rack with adapter)
- Fully digital regulation via microcontroller + FPGA for fast signal processing and adaptable load response
- Electrically reversible polarity (positive or negative HV output)
- User-friendly operating system with intuitive controls
- High power density and quick, precise control without compromising speed or accuracy
Contact our team to discuss custom specifications for your optimal high-voltage supply solution.
Learn more on this Youtube Video.
Overview
Applications
- Driving high power laser diodes, bars and arrays in pulsed, QCW or CW modes.
Features
- 1 A To 125 A Output Current
- Less than 100 ns to DC Variable Pulse Width
- 20 V Maximum Output Voltage
- 2.5 kW Maximum Average Output Power
- User-Adjustable Variable Rise Time
- Repetition Frequency Single-Shot to 500 kHz
Specifications
Compliance Voltage
20V
Max Current Amplitude
125A
Rise/Fall Time
30ns
Max Frequency
500 kHz
Pulse Engine (Trigger)
External
Remote Control
N/A
Form Factor
Module
Cooling
Ambient Air
Dimensions (in)
12x10x10
Weight (lbs)
10
