Microwave & RF Signal Generators

Microwave & RF Signal Generators

  • Model 845

    Model 845 — 12, 20, & 26.5 GHz Microwave Signal Generator / RF Signal Generator

    Berkeley Nucleonics' Model 845 RF Microwave Signal Generator is a low-noise and fast-switching microwave signal generator covering a frequency range from 100 kHz up to 26.5 GHz. The Model 845 Microwave... Read more

    • Frequency and power switching time down to 10us
    • 500MHz at 1KHz offset: -131 dBc/Hz
    • 4GHz at 1KHz offset: -115 dBC /Hz
  • Model 845-M

    Model 845-M — 0.01 to 20 GHz Low Noise Synthesizer

    The 845-M is a wideband low phase-noise synthesizer operating up to 20 GHz. The module has a mili-Hz frequency resolution and uses a high-stability internal reference. The internal reference can be phase-locked to a programmable external reference.

    The module has a USB and LAN interface and can be controlled using SCPI 1999 command sets. This small module operates with... Read more

    • Low phase noise
    • Fast Switching
    • Wideband DC frequency modulation
  • Model 845-OEM — Up to 26.5 GHz OEM Microwave Signal Generator / RF Signal Generator

    The Model 845-OEM series is an easy to implement test equipment solution designed to fulfill your signal generation needs. Built on a foundation of high quality and market leading Berkeley Nucleonics Signal ... Read more
    • High Output Power: +27 dBm @ 1 GHz with HP option
    • Wide Frequency Range: 100 kHz to 26.5 GHz
    • Excellent Phase Noise Performance: -100 dBc/Hz @ 1 kHz Offset @ 10 GHz
  • Model 835-6

    Model 835-6 — 6 GHz Signal Generator

    Berkeley Nucleonics' Model 835-6 is a low-noise, fast-switching analog signal generator that covers a frequency range from 9 kHz up to 6.1 GHz.

    The Model 835-6 provides full RF signal generator capabilities including OCXO-stabilized low phase noise signal with micro-Hz frequency... Read more

    • Only 200 µs frequency switching time
    • Excellent SSB phase noise
    • Comprehensive AM, low-distortion
  • Model 835-4

    Model 835-4 — 4 GHz Signal Generator

    Berkeley Nucleonics' Model 835-4 is a low-noise, fast-switching analog signal generator that covers a frequency range from 9 kHz up to 4 GHz.

    The Model 835-4 is a low phase noise, fast-switching RF signal generator with µHz frequency resolution, and precisely leveled power range from -120 to... Read more

    • Only 200 µs frequency switching time
    • Excellent SSB phase noise
    • Comprehensive AM, low-distortion
  • Model 835-M

    Model 835-M — Ultra-Compact, General-Purpose RF Signal Generator

    The Model 835-M is a versatile, ultra-compact general-purpose radio frequency signal generator covering a frequency range from 9kHz to 3.0GHz with 0.1 Hz frequency resolution, very good signal quality, and powerful trigger features. It is ideally suited for a wide range of applications where good signal quality, fast switching, and an accurate and wide output power range is required. The Model... Read more

    • Very compact and rugged enclosure
    • 0.1 Hz to 50 kHz rate AM and fast pulse modulator
    • LAN + USB + GPIB (optional) with SCPI instruction set
