#### NP6-DP-BNC | Standard Series 3.11ft Parabolic Antenna

 The NP6-DP-BNC Standard Series offers a cost-effective, 5.9-7.2 GHz, up to 31 miles (50km), 3.11ft parabolic antenna engineered to deliver reliable radio links with a stable 32 dBi gain from 5.9 to 7.2 GHz.

##### [Features](#features-section)

##### [Specifications](#specifications-section)

##### [Tech Resources](#technical-resources-section)

##### [Downloable Resources](#downloadable-section)

##### [Price List](#pricelist-section)

#### Overview

##### Applications

- Various Point to Point Communication
- Satellite Communication
- Spacecraft Communication
- Wireless WAN/LAN Links
- Radar Communication

##### Features

- Gain of up to 32 dBi with low VSWR and high port isolation across the entire 5.9 – 7.2 GHz band
- One antenna that covers 6 and 7 GHz
- Reduced interference with 35 dB minimum front to back
- Simplifies installation on site and guarantees “factory-tested” quality
- Pigtails of N to RPSMA included in the box

#### Specifications

**Frequency**

5.9 – 7.2 GHz

**Gain (dBi)**

**30:** 5.9 GHz
**31.5:** 6.8 GHz
**32:** 7.2 GHz

**VSWR HPOL**

<2.0

**Polarization**

Vertical – Horizontal

**Beamwidth**

**VPOL:** >3.0°
**HPOL:** <3.2°

**Wind max survival speed (MPH)**

124.2 MPH with Radome

**Elevation adjustment (°)**

+/- 15°
